3d Scanning Doppler Wind Lidar , Onshore Offshore Lidar Wind Measurement

Brand Name : MOVELASER

Model Number : Molas 3D

Place of Origin : China

MOQ : 1 set

Price : Dollar 13W$+ （Price consultation customer service）

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 200 set ，1 month

Delivery Time : 1-2 months

Packaging Details : Air Box

Pointing Accuracy : 0.1°

Distance resolution : 30m, 75m

accumulation time : 0.5s/1s/2s/4s/8s optional

Radial wind speed measurement accuracy : 0.1m/s

Vertical Range : -10°~190°

Laser Safety Level : IEC 60825-1 (2014) Class 1M Eye Safety

name : 3d Scanning Doppler Wind Lidar , Onshore Offshore Lidar Wind Measurement

keyword : doppler wind lidar

Contact Now

Doppler wind lidar 3D Scanning Doppler onshore offshore Wind Lidar measurement

| Product introduction

Molas 3D 3D scanning wind lidar is a lidar system based on the above principles, with an additional scanner that can freely adjust the beam direction. It can perform specific scanning methods for specific airspace ranges, providing all-weather, omnidirectional, real-time, high-precision wind field information, and can be used for urban meteorological observation, wind power resource assessment, local wind shear early warning, high altitude turbulence, wind tunnel aerodynamics research Application scenarios such as complex terrain and offshore wind power resource assessment.

| Application scenarios

Real-time 3D information on plume dispersion to track emission sources
Optimizing Dust Emission Control for the Mining Industry

| Product parameters

Basic parameters
Line-of-sight detection distance 8km (corresponding to 75m distance resolution)
4km (corresponding to 30m distance resolution)
Distance resolution 30m/45m/60m/75m optional
Accumulation time 0.5s/1s/2s/4s/8s optional
Radial wind speed measurement range -75~+75 m/s
Radial wind speed measurement accuracy 0.1m/s
Number of distance layers up to 300
Horizontal scan range 360° × n
Vertical scan range -10°~190°


| Product Features


Rich measurement information:3D wind field refined measurement, up to 300 custom distance layers
large range:4/8km typical detection distance
High precision:Pointing accuracy 0.1°, visual direction wind speed accuracy 0.1m/s
Rich scanning methods:PPI/RHI/DBS/LOS/ Programmable arbitrary scan method
Flexible deployment:Small and lightweight, easy to transition and build
all-weather:No fear of harsh wild environment, with LPZ0B minefield survivability
Safe to use:With GPS location reporting and geo-fencing functions, data encryption has no risk of leakage
Rich configuration:2 distance resolutions and 5 accumulation times to choose from

| Product Image

3d Scanning Doppler Wind Lidar , Onshore Offshore Lidar Wind Measurement
